Videotelephony comprises the technologies for the reception and transmission of audio-video signals by users at different locations, for communication between people in real time.^[1] A videophone is a telephone with a video display, capable of simultaneous video and audio for communication between people in real time. Videoconferencing implies the use of this technology for a group or organizational meeting rather than for individuals, in a videoconference.^[2]Telepresence may refer either to a high-quality videotelephony system (where the goal is to create the illusion that remote participants are in the same room) or to meetup technology, which goes beyond video into robotics (such as moving around the room or physically manipulating objects). Videoconferencing has also been called "visual collaboration" and is a type of groupware.

While development of video conferencing started in the late 19th century, the technology only became available to the public starting in the 1930s. These early demonstrations were installed at "booths" in post offices and shown at various world expositions. It took until 1970 for AT&T to launch the first true video conferencing system, wherein anyone could subscribe to the service and have the technology in their home or office. Videotelephony also included "image phones" which would exchange still images between units every few seconds over conventional plain old telephone service (POTS) lines, essentially the same as slow-scan TV. The development of advanced video codecs, more powerful CPUs, and high-bandwidth Internet telecommunication services in the late 1990s allowed videophones to provide high quality low-cost colour service between users almost any place in the world where the Internet is available.

Although not as widely used in everyday communications as audio-only and text communication, useful applications include sign language transmission for deaf and speech-impaired people, distance education, telemedicine, and overcoming mobility issues. It is also used in commercial and corporate settings to facilitate meetings and conferences, typically between parties that already have established relationships. News media organizations have begun to use desktop technologies like Skype to provide higher-quality audio than the cellular phone network, and video links at much lower cost than sending professional equipment or using a professional studio.^{[citation needed]} More popular videotelephony technologies use the Internet rather than the traditional landline phone network, even accounting for modern digital packetized phone network protocols, and even though videotelephony software commonly runs on smartphones.

History[edit]

Video telephony predicted to be in use by the year 2000, as envisioned in 1910 (artist's conception)

Video telephone booth, 1930

The concept of videotelephony was first conceived in the late 1870s both in the United States and in Europe, although the basic sciences to permit its very earliest trials would take nearly a half century to be discovered.^{[citation needed]} This was first embodied in the device which came to be known as the video telephone, or videophone, and it evolved from intensive research and experimentation in several telecommunication fields, notably electrical telegraphy, telephony, radio, and television.

Simple analog videophone communication could be established as early as the invention of the television. Such an antecedent usually consisted of two closed-circuit television systems connected via coax cable or radio. An example of that was the German Reich Postzentralamt (post office) video telephone network serving Berlin and several German cities via coaxial cables between 1936 and 1940.^[3][4]

The development of video conferencing as a subscription service started in the latter half of the 1920s in the United Kingdom and the United States, spurred notably by John Logie Baird and AT&T's Bell Labs. This occurred in part, at least with AT&T, to serve as an adjunct supplementing the use of the telephone. A number of organizations believed that videotelephony would be superior to plain voice communications. Attempts at using normal telephony networks to transmit slow-scan video, such as the first systems developed by AT&T Corporation, first researched in the 1950s, failed mostly due to the poor picture quality and the lack of efficient video compression techniques.

The first manned space flights, NASA used two radio-frequency (UHF or VHF) video links, one in each direction. TV channels routinely use this type of videotelephony when reporting from distant locations. The news media were to become regular users of mobile links to satellites using specially equipped trucks, and much later via special satellite videophones in a briefcase. This technique was very expensive, though, and could not be used for applications such as telemedicine, distance education, and business meetings.

Decades of research and development culminated in the 1970 commercial launch of AT&T's Picturephone service, available in select cities. However, the system was a commercial failure, chiefly due to consumer apathy, high subscription costs, and lack of network effect—with only a few hundred Picturephones in the world, users had extremely few contacts they could actually call, and interoperability with other videophone systems would not exist for decades.

Very expensive videoconferencing systems continued to evolve throughout the 1980s and 1990s. Proprietary equipment, software, and network requirements gave way to standards-based technologies that were available for anyone to purchase at a reasonable cost. Only in the late 20th century with the advent of powerful video codecs combined with high-speed Internet broadband and ISDN service did videotelephony become a practical technology for regular use.

Digital[edit]

Practical digital videotelephony was made possible only with advances in video compression, due to the impractically high bandwidth requirements of uncompressed video. To achieve Video Graphics Array (VGA) quality video (480p resolution and 256 colors) with raw uncompressed video, it would require a bandwidth of over 92 Mbps.^[5] The most important compression technique that enabled practical digital videotelephony and videoconferencing is the discrete cosine transform (DCT).^[5][6] The DCT, a form of lossy compression, was conceived in 1972 by Nasir Ahmed, who developed the algorithm with T. Natarajan and K. R. Rao at the University of Texas in 1973.^[7] The DCT algorithm became the basis for the first practical video coding standard that was useful for online videoconferencing, H.261, standardised by the ITU-T in 1988, and subsequent H.26xvideo coding standards.^[6]

In the 1980s, digital telephony transmission networks became possible, such as with ISDN networks, assuring a minimum bit rate (usually 128 kilobits/s) for compressed video and audio transmission. During this time, there was also research into other forms of digital video and audio communication. Many of these technologies, such as the Media space, are not as widely used today as videoconferencing but were still an important area of research.^[8][9] The first dedicated systems started to appear as ISDN networks were expanding throughout the world. One of the first commercial videoconferencing systems sold to companies came from PictureTel Corp., which had an initial public offering in November, 1984.

In 1984, Concept Communication in the United States replaced the hundred pound, US$100,000 computers necessary for teleconferencing, with a $12,000 circuit board that doubled the video frame rate from 15 to 30 frames per second, and which reduced the equipment to the size of a circuit board fitting into standard personal computers.^[10] The company also secured a patent for a codec for full-motion videoconferencing, first demonstrated at AT&T Bell Labs in 1986.^[10][11]

Global Schoolhouse students communicating via CU-SeeMe, with a video framerate between three and nine frames per second (1993).

Videoconferencing systems throughout the 1990s rapidly evolved from very expensive proprietary equipment, software, and network requirements to a standards-based technology readily available to the general public at a reasonable cost.

Finally, in the 1990s, Internet Protocol-based videoconferencing became possible, and more efficient video compression technologies were developed, permitting desktop, or personal computer (PC)-based videoconferencing. In 1992 CU-SeeMe was developed at Cornell by Tim Dorcey et al. In 1995 the first public videoconference between North America and Africa took place, linking a technofair in San Francisco with a techno-rave and cyberdeli in Cape Town. At the 1998 Winter Olympics opening ceremony in Nagano, Japan, Seiji Ozawa conducted the Ode to Joy from Beethoven's Ninth Symphony simultaneously across five continents in near-real-time.

While videoconferencing technology was initially used primarily within internal corporate communication networks, one of the first community service usages of the technology started in 1992 through a unique partnership with PictureTel and IBM Corporations which at the time were promoting a jointly developed desktop based videoconferencing product known as the PCS/1. Over the next 15 years, Project DIANE (Diversified Information and Assistance Network) grew to utilize a variety of videoconferencing platforms to create a multi-state cooperative public service and distance education network consisting of several hundred schools, libraries, science museums, zoos and parks, and many other community oriented organizations.

The Kyocera VP-210 Visual Phone was the first commercial mobile videophone (1999).

Kyocera conducted a two-year development campaign from 1997 to 1999 that resulted in the release of the VP-210 Visual Phone, the first mobile colour videophone that also doubled as a camera phone for still photos.^[12][13] The camera phone was the same size as similar contemporary mobile phones, but sported a large camera lens and a 5 cm (2 inch) colour TFT display capable of displaying 65,000 colors, and was able to process two video frames per second.^[13][14]

Videotelephony was popularized in the 2000s, via free Internet services such as Skype and iChat, web plugins supporting H.26x video standards, and on-line telecommunication programs that promoted low cost, albeit lower quality, videoconferencing to virtually every location with an Internet connection.

Russian President Dmitry Medvedev attending the Singapore APEC summit, holding a videoconference with Rashid Nurgaliyev via a Tactical MXP, after an arms depot explosion in Russia (2009)

With the rapid improvements and popularity of the Internet, videotelephony has become widespread through the deployment of video-enabled mobile phones such as 2010's iPhone 4, plus videoconferencing and computer webcams which utilize Internet telephony. In the upper echelons of government, business, and commerce, telepresence technology, an advanced form of videoconferencing, has helped reduce the need to travel.^{[citation needed]}

In May 2005, the first high definition video conferencing systems, produced by LifeSize Communications, were displayed at the Interop trade show in Las Vegas, Nevada, able to provide video at 30 frames per second with a 1280 by 720 display resolution.^[15][16]Polycom introduced its first high definition video conferencing system to the market in 2006. As of the 2010s, high definition resolution for videoconferencing became a popular feature, with most major suppliers in the videoconferencing market offering it.

Technological developments by videoconferencing developers in the 2010s have extended the capabilities of video conferencing systems beyond the boardroom for use with hand-held mobile devices that combine the use of video, audio and on-screen drawing capabilities broadcasting in real time over secure networks, independent of location. Mobile collaboration systems now allow people in previously unreachable locations, such as workers on an offshore oil rig, the ability to view and discuss issues with colleagues thousands of miles away. Traditional videoconferencing system manufacturers have begun providing mobile applications as well, such as those that allow for live and still image streaming.^[17]

The highest ever video call (other than those from aircraft and spacecraft) took place on May 19, 2013, when British adventurer Daniel Hughes used a smartphone with a BGAN satellite modem to make a videocall to the BBC from the summit of Mount Everest, at 8,848 metres (29,029 ft) above sea level.^[18]

The COVID-19 pandemic resulted in a significant increase in the use of videoconferencing. Berstein Research found that Zoom added more subscribers during the first two months of 2020 alone than in the entire year 2019. GoToMeeting had a 20 percent increase in usage, according to LogMeIn.^[19] UK based StarLeaf reported a 600 percent increase in national call volumes.^[20]

Major categories[edit]

A modern AvayaNortel 1535 IP model broadband videophone (2008), using VoIP

An older dual-display Polycom videoconferencing system (2008)

A typical low-cost webcam for use with personal computers (2006)

Videotelephony can be categorized by its functionality, that is to its intended purpose, and also by its method of transmissions.

Videophones were the earliest form of videotelephony, dating back to initial tests in 1927 by AT&T. During the late 1930s, the post offices of several European governments established public videophone services for person-to-person communications utilizing dual cable circuit telephone transmission technology. In the present day, standalone videophones and UMTS video-enabled mobile phones are usually used on a person-to-person basis.

Videoconferencing saw its earliest use with AT&T's Picturephone service in the early 1970s. Transmissions were analog over short distances, but converted to digital forms for longer calls, again using telephone transmission technology. Popular corporate video-conferencing systems in the present day have migrated almost exclusively to digital ISDN and IP transmission modes due to the need to convey the very large amounts of data generated by their cameras and microphones. These systems are often intended for use in conference mode, that is by many people in several different locations, all of whom can be viewed by every participant at each location.

Telepresence systems are a newer, more advanced subset of videoconferencing systems, meant to allow higher degrees of video and audio fidelity. Such high-end systems are typically deployed in corporate settings.

Mobile collaboration systems are another recent development, combining the use of video, audio, and on-screen drawing capabilities using newest generation hand-held electronic devices broadcasting over secure networks, enabling multi-party conferencing in real time, independent of location.

A more recent technology encompassing these functions is TV cams. TV cams enable people to make video "phone" calls using video calling services, like Skype on their TV, without using a PC connection. TV cams are specially designed video cameras that feed images in real time to another TV camera or other compatible computing devices like smartphones, tablets and computers.

Webcams are popular, relatively low cost devices which can provide live video and audio streams via personal computers, and can be used with many software clients for both video calls and videoconferencing.^[21]

Each of the systems has its own advantages and disadvantages, including video quality, capital cost, degrees of sophistication, transmission capacity requirements, and cost of use.

By cost and quality of service[edit]

From the least to the most expensive systems:

• Web camera videophone and videoconferencing systems, either stand-alone or built-in, that serve as complements to personal computers, connected to other participants by computer and VoIP networks—lowest direct cost, assuming the users already possess computers at their respective locations. Quality of service can range from low to very high, including high definition video available on the latest model webcams. A related and similar device is a TV camera which is usually small, sits on top of a TV, and can connect to it via its HDMI port, similar to how a webcam attaches to a computer via a USB port.
• Videophones—low to midrange cost. The earliest standalone models operated over either plain old telephone service (POTS) lines on the PSTN telephone networks or more expensive ISDN lines, while newer models have largely migrated to Internet protocol line service for higher image resolutions and sound quality. Quality of service for standalone videophones can vary from low to high;
• Huddle room or all-in-one systems —low to midrange cost, newer endpoint category based on standard videoconferencing systems, but defined by the camera, microphone(s), speakers, and codec contained in a single piece of hardware. Typically used in small to medium spaces where beamformingmicrophone arrays located in the system are sufficient, in lieu of table or ceiling microphones in closer proximity to the in room participants. Quality of service is comparable to standard videoconferencing systems, varying from moderate to high. Some manufacturers' huddle room systems do not include the codec within the soundbar shaped unit, rather only camera, microphone, and speakers. These systems are usually still classified as huddle room systems, but, like webcams, rely on a USB connection to an external device, usually a PC, to process the video codec responsibilities.
• Videoconferencing systems—midrange cost, usually utilizing multipoint control units or other bridging services to allow multiple parties on videoconference calls. Quality of service can vary from moderate to high.
• Telepresence systems—highest capabilities and highest cost. Full high-end systems can involve specially built teleconference rooms to allow expansive views with very high levels of audio and video fidelity, to permit an 'immersive' videoconference. When the proper type and capacity transmission lines are provided between facilities, the quality of service reaches state-of-the-art levels.

Security concerns[edit]

Computer security experts have shown that poorly configured or inadequately supervised videoconferencing system can permit an easy "virtual" entry by computer hackers and criminals into company premises and corporate boardrooms, via their own videoconferencing systems.^[22]

Adoption[edit]

For over a century, futurists have envisioned a future where telephone conversations will take place as actual face-to-face encounters with video as well as audio. Sometimes it is simply not possible or practical to have face-to-face meetings with two or more people. Sometimes a telephone conversation or conference call is adequate. Other times, e-mail exchanges are adequate. However, videoconferencing adds another possible alternative, and can be considered when:

• A live conversation is needed
• Non-verbal (visual) information is an important component of the conversation
• The parties of the conversation can't physically come to the same location
• The expense or time of travel is a consideration

Bill Gates said in 2001 that he used video conferencing "three or four times a year", because digital scheduling was difficult and "if the overhead is super high, then you might as well just have a face-to-face meeting".^[23] Some observers argue that three outstanding issues have prevented videoconferencing from becoming a widely adopted form of communication, despite the ubiquity of videoconferencing-capable systems.^[24]

• Eye contact:Eye contact plays a large role in conversational turn-taking, perceived attention and intent, and other aspects of group communication.^[25] While traditional telephone conversations give no eye contact cues, many videoconferencing systems are arguably worse in that they provide an incorrect impression that the remote interlocutor is avoiding eye contact. Some telepresence systems have cameras located in the screens that reduce the amount of parallax observed by the users. This issue is also being addressed through research that generates a synthetic image with eye contact using stereo reconstruction.^[26]
  Telcordia Technologies, formerly Bell Communications Research, owns a patent for eye-to-eye videoconferencing using rear projection screens with the video camera behind it, evolved from a 1960s U.S. military system that provided videoconferencing services between the White House and various other government and military facilities. This technique eliminates the need for special cameras or image processing.^[27]
• Appearance consciousness: A second psychological problem with videoconferencing is being on camera, with the video stream possibly even being recorded. The burden of presenting an acceptable on-screen appearance is not present in audio-only communication. Early studies by Alphonse Chapanis found that the addition of video actually impaired communication, possibly because of the consciousness of being on camera.^[28]
• Signal latency: The information transport of digital signals in many steps need time. In a telecommunicated conversation, an increased latency (time lag) larger than about 150–300 ms becomes noticeable and is soon observed as unnatural and distracting. Therefore, next to a stable large bandwidth, a small total round-trip time is another major technical requirement for the communication channel for interactive videoconferencing.^[29]
• Bandwidth and quality of service: In some countries, it is difficult or expensive to get a high quality connection that is fast enough for good-quality video conferencing. Technologies such as ADSL are usually provided as two separate lines (for uplink/downlink) because each has limited upload speeds and cannot upload and download simultaneously at full speed. As Internet speeds increase higher quality and high definition video conferencing will become more readily available.
• Complexity of systems: Most users are not technical and want a simple interface. In hardware systems, an unplugged cord or a dead battery in remote control is seen as a failure, contributing to a perceived unreliability. Successful systems are backed by support teams who can pro-actively support and provide fast assistance when required.
• Perceived lack of interoperability: not all systems can readily interconnect, for example, ISDN and IP systems require a gateway. Popular software solutions cannot easily connect to hardware systems. Some systems use different standards, features, and qualities which can require additional configuration when connecting to dissimilar systems. Free software systems circumvent this limitation by making it relatively easy for a single user to communicate over multiple incompatible platforms.
• Expense of commercial systems: well-designed telepresence systems require specially designed rooms which can cost hundreds of thousands of dollars to fit out their rooms with codecs, integration equipment (such as Multipoint Control Units), high fidelity sound systems, and furniture. Monthly charges may also be required for bridging services and high capacity broadband service.

These are some of the reasons many systems are often used for internal corporate use only, as they are less likely to result in lost sales. One alternative to companies lacking dedicated facilities is the rental of videoconferencing-equipped meeting rooms in cities around the world. Clients can book rooms and turn up for the meeting, with all technical aspects being prearranged and support being readily available if needed. The issue of eye-contact may be solved with advancing technology, including smartphones which have the screen and camera in essentially the same place. The ubiquity of smartphones, tablet computers, and computers with built-in audio and webcams in developed countries obviates the need to buy expensive hardware.

Technology[edit]

Components and types[edit]

Dual display: An older Polycom VSX 7000 system and camera used for videoconferencing, with two displays for simultaneous broadcast from separate locations

The core technology used in a videotelephony system is digital compression of audio and video streams in real time. The hardware or software that performs compression is called a codec (coder/decoder). Compression rates of up to 1:500 can be achieved. The resulting digital stream of 1s and 0s is subdivided into labeled packets, which are then transmitted through a digital network of some kind (usually ISDN or IP).

The other components required for a videoconferencing system include:

• Video input: (PTZ / 360° / Fisheye) video camera, or webcam
• Video output: computer monitor, television, or projector
• Audio input: microphones, CD/DVD player, cassette player, or any other source of PreAmp audio outlet.
• Audio output: usually loudspeakers associated with the display device or telephone
• Data transfer: analog or digital telephone network, LAN, or Internet
• Computer: a data processing unit that ties together the other components, does the compressing and decompressing, and initiates and maintains the data linkage via the network.

There are basically two kinds of videoconferencing and videophone systems:

1. Dedicated systems have all required components packaged into a single piece of equipment, usually a console with a high quality remote controlled video camera. These cameras can be controlled at a distance to pan left and right, tilt up and down, and zoom. They became known as PTZ cameras. The console contains all electrical interfaces, the control computer, and the software or hardware-based codec. Omnidirectional microphones are connected to the console, as well as a TV monitor with loudspeakers and/or a video projector. There are several types of dedicated videoconferencing devices:
   1. Large group videoconferencing are built-in, large, expensive devices used for large rooms such as conference rooms and auditoriums.
   2. Small group videoconferencing are either non-portable or portable, smaller, less expensive devices used for small meeting rooms.
   3. Individual videoconferencing are usually portable devices, meant for single users, and have fixed cameras, microphones, and loudspeakers integrated into the console.
2. Desktop systems are add-ons (hardware boards or software codec) to normal PCs and laptops, transforming them into videoconferencing devices. A range of different cameras and microphones can be used with the codec, which contains the necessary codec and transmission interfaces. Most of the desktops systems work with the H.323 standard.
3. WebRTC Platforms are video conferencing solutions that are not resident by using a software application but is available through the standard web browser. Solutions such as Adobe Connect and Cisco WebEX can be accessed by going to a URL sent by the meeting organizer and various degrees of security can be attached to the virtual "room". Often the user will be required to download a piece of software, called an "Add In" to enable the browser to access the local camera, microphone and establish a connection to the meeting. WebRTC technology doesn't require any software or Add On installation, instead a WebRTC compliant internet browser itself acts as a client to facilitate 1-to-1 and 1-to-many videoconferencing calls. Several enhanced flavours of WebRTC technology are being provided by Third Party vendors.

Videoconferencing modes[edit]

Videoconferencing systems use two methods to determine which video feed or feeds to display.

Continuous Presence simply displays all participants at the same time,^[30] usually with the exception that the viewer either does not see their own feed, or sees their own feed in miniature.

Voice-Activated Switch selectively chooses a feed to display at each endpoint, with the goal of showing the person who is currently speaking. This is done by choosing the feed (other than the viewer) which has the loudest audio input (perhaps with some filtering to avoid switching for very short-lived volume spikes). Often if no remote parties are currently speaking, the feed with the last speaker remains on the screen.

Echo cancellation[edit]

Acoustic echo cancellation (AEC) is a processing algorithm that uses the knowledge of audio output to monitor audio input and filter from it noises that echo back after some time delay. If unattended, these echoes can be re-amplified several times, leading to problems including:

• The remote party hearing their own voice coming back at them (usually significantly delayed)

1. Strong reverberation, which makes the voice channel useless
2. Howling created by feedback

Echo cancellation is a processor-intensive task that usually works over a narrow range of sound delays.

Bandwidth requirements[edit]

Deutsche Telekom T-View 100ISDN-type videophone meant for home offices and small businesses, with a lens cover which can be rotated upward for privacy

Videophones have historically employed a variety of transmission and reception bandwidths, which can be understood as data transmission speeds. The lower the transmission/reception bandwidth, the lower the data transfer rate, resulting in a progressively limited and poorer image quality (i.e. lower resolution and/or frame rate). Data transfer rates and live video image quality are related, but are also subject to other factors such as data compression techniques. Some early videophones employed very low data transmission rates with a resulting poor video quality.

Broadband bandwidth is often called "high-speed", because it usually has a high rate of data transmission. In general, any connection of 256 kbit/s (0.256 Mbit/s) or greater is more concisely considered broadband Internet. The International Telecommunication Union Telecommunication Standardization Sector (ITU-T) recommendation I.113 has defined broadband as a transmission capacity at 1.5 to 2 Mbit/s. The Federal Communications Commission (United States) definition of broadband is 25 Mbit/s.^[31]

Currently, adequate video for some purposes becomes possible at data rates lower than the ITU-T broadband definition, with rates of 768 kbit/s and 384 kbit/s used for some video conferencing applications, and rates as low as 100 kbit/s used for videophones using H.264/MPEG-4 AVC compression protocols. The newer MPEG-4video and audio compression format can deliver high-quality video at 2 Mbit/s, which is at the low end of cable modem and ADSL broadband performance.^{[citation needed]}

Standards[edit]

The Tandberg E20 is an example of a SIP-only device. Such devices need to route calls through a Video Communication Server to be able to reach H.323 systems, a process known as "interworking" (2009).

The International Telecommunications Union (ITU) has three umbrellas of standards for videoconferencing:

• ITU H.320 is known as the standard for public switched telephone networks (PSTN) or videoconferencing over integrated services digital networks. While still prevalent in Europe, ISDN was never widely adopted in the United States and Canada.^{[citation needed]}
• ITU H.264Scalable Video Coding (SVC) is a compression standard that enables videoconferencing systems to achieve highly error resilient Internet Protocol (IP) video transmissions over the public Internet without quality-of-service enhanced lines.^[32] This standard has enabled wide scale deployment of high definition desktop videoconferencing and made possible new architectures,^[33] which reduces latency between the transmitting sources and receivers, resulting in more fluid communication without pauses. In addition, an attractive factor for IP videoconferencing is that it is easier to set up for use along with web conferencing and data collaboration. These combined technologies enable users to have a richer multimedia environment for live meetings, collaboration and presentations.
• ITU V.80: videoconferencing is generally compatibilized with H.324 standard point-to-point videotelephony over regular (POTS) phone lines.

The Unified Communications Interoperability Forum (UCIF), a non-profit alliance between communications vendors, launched in May 2010. The organization's vision is to maximize the interoperability of UC based on existing standards. Founding members of UCIF include HP, Microsoft, Polycom, Logitech/LifeSize Communications, and Juniper Networks.^[34][35]

Call setup[edit]

Videoconferencing in the late 20th century was limited to the H.323 protocol (notably Cisco's SCCP implementation was an exception), but newer videophones often use SIP, which is often easier to set up in home networking environments.^[36] It is a text-based protocol, incorporating many elements of the Hypertext Transfer Protocol (HTTP) and the Simple Mail Transfer Protocol (SMTP).^[37] H.323 is still used, but more commonly for business videoconferencing, while SIP is more commonly used in personal consumer videophones. A number of call-setup methods based on instant messaging protocols such as Skype also now provide video.

Another protocol used by videophones is H.324, which mixes call setup and video compression. Videophones that work on regular phone lines typically use H.324, but the bandwidth is limited by the modem to around 33 kbit/s, limiting the video quality and frame rate. A slightly modified version of H.324 called 3G-324M defined by 3GPP is also used by some cellphones that allow video calls, typically for use only in UMTS networks.^[38][39]

There is also H.320 standard, which specified technical requirements for narrow-band visual telephone systems and terminal equipment, typically for videoconferencing and videophone services. It applied mostly to dedicated circuit-based switched network (point-to-point) connections of moderate or high bandwidth, such as through the medium-bandwidth ISDN digital phone protocol or a fractionated high bandwidth T1 lines. Modern products based on H.320 standard usually support also H.323 standard.^[40]

The IAX2 protocol also supports videophone calls natively, using the protocol's own capabilities to transport alternate media streams. A few hobbyists obtained the Nortel 1535 Color SIP Videophone cheaply in 2010 as surplus after Nortel's bankruptcy and deployed the sets on the Asterisk (PBX) platform. While additional software is required to patch together multiple video feeds for conference calls or convert between dissimilar video standards, SIP calls between two identical handsets within the same PBX were relatively straightforward.^[41]

Conferencing layers[edit]

The components within a videoconferencing system can be divided up into several different layers: User Interface, Conference Control, Control or Signaling Plane, and Media Plane.

Videoconferencing User Interfaces (VUI) can be either graphical or voice-responsive. Many in the industry have encountered both types of interface, and normally a graphical interface is encountered on a computer. User interfaces for conferencing have a number of different uses; they can be used for scheduling, setup, and making a videocall. Through the user interface the administrator is able to control the other three layers of the system.

Conference Control performs resource allocation, management, and routing. This layer along with the User Interface creates meetings (scheduled or unscheduled) or adds and removes participants from a conference.

Control (Signaling) Plane contains the stacks that signal different endpoints to create a call and/or a conference. Signals can be, but aren't limited to, H.323 and Session Initiation Protocol (SIP) Protocols. These signals control incoming and outgoing connections as well as session parameters.

The Media Plane controls the audio and video mixing and streaming. This layer manages Real-Time Transport Protocols, User Datagram Packets (UDP) and Real-Time Transport Control Protocol (RTCP). The RTP and UDP normally carry information such the payload type which is the type of codec, frame rate, video size, and many others. RTCP on the other hand acts as a quality control Protocol for detecting errors during streaming.^[30]

Multipoint control[edit]

Simultaneous videoconferencing among three or more remote points is possible in a hardware-based system by means of a Multipoint Control Unit (MCU). This is a bridge that interconnects calls from several sources (in a similar way to the audio conference call). All parties call the MCU, or the MCU can also call the parties which are going to participate, in sequence. There are MCU bridges for IP and ISDN-based videoconferencing. There are MCUs which are pure software, and others which are a combination of hardware and software. An MCU is characterised according to the number of simultaneous calls it can handle, its ability to conduct transposing of data rates and protocols, and features such as Continuous Presence, in which multiple parties can be seen on-screen at once. MCUs can be stand-alone hardware devices, or they can be embedded into dedicated videoconferencing units.

The MCU consists of two logical components:

1. A single multipoint controller (MC), and
2. Multipoint Processors (MP), sometimes referred to as the mixer.

The MC controls the conferencing while it is active on the signaling plane, which is simply where the system manages conferencing creation, endpoint signaling and in-conferencing controls. This component negotiates parameters with every endpoint in the network and controls conferencing resources. While the MC controls resources and signaling negotiations, the MP operates on the media plane and receives media from each endpoint. The MP generates output streams from each endpoint and redirects the information to other endpoints in the conference.

Some systems are capable of multipoint conferencing with no MCU, stand-alone, embedded or otherwise. These use a standards-based H.323 technique known as "decentralized multipoint", where each station in a multipoint call exchanges video and audio directly with the other stations with no central "manager" or other bottleneck. The advantages of this technique are that the video and audio will generally be of higher quality because they don't have to be relayed through a central point. Also, users can make ad hoc multipoint calls without any concern for the availability or control of an MCU. This added convenience and quality comes at the expense of some increased network bandwidth, because every station must transmit to every other station directly.^[30]

Cloud storage[edit]

Cloud-based video conferencing can be used without the hardware generally required by other video conferencing systems, and can be designed for use by SMEs,^[42] or larger international or multinational corporations like Facebook.^[43][44] Cloud-based systems can handle either 2D or 3D video broadcasting.^[45] Cloud-based systems can also implement mobile calls, VOIP, and other forms of video calling. They can also come with a video recording function to archive past meetings.^[46]

Impact[edit]

This article needs to be updated. Please update this article to reflect recent events or newly available information.(February 2015)

High speed Internet connectivity has become more widely available at a reasonable cost and the cost of video capture and display technology has decreased. Consequently, personal videoconferencing systems based on a webcam, personal computer system, software compression, and broadband Internet connectivity have become progressively more affordable to the general public. Also, the hardware used for this technology has continued to improve in quality, and prices have dropped dramatically. The availability of freeware (often as part of chat programs) has made software based videoconferencing accessible to many.

The widest deployment of video telephony now occurs in mobile phones. Nearly all mobile phones supporting UMTS networks can work as videophones using their internal cameras and are able to make video calls wirelessly to other UMTS users in the same country or internationally.^{[citation needed]} As of the second quarter of 2007, there are over 131 million UMTS users (and hence potential videophone users), on 134 networks in 59 countries.^{[citation needed]} Mobile phones can also use broadband wireless Internet, whether through the cell phone network or over a local wifi connection, along with software-based videophone apps to make calls to any video-capable Internet user, whether mobile or fixed.

Deaf, hard-of-hearing, and mute individuals have a particular role in the development of affordable high-quality videotelephony as a means of communicating with each other in sign language. Unlike Video Relay Service, which is intended to support communication between a caller using sign language and another party using spoken language, videoconferencing can be used directly between two deaf signers.

Videophones are increasingly used in the provision of telemedicine to the elderly, disabled, and to those in remote locations, where the ease and convenience of quickly obtaining diagnostic and consultative medical services are readily apparent.^[47] In one single instance quoted in 2006: "A nurse-led clinic at Letham has received positive feedback on a trial of a video-link which allowed 60 pensioners to be assessed by medics without travelling to a doctor's office or medical clinic."^[47] A further improvement in telemedical services has been the development of new technology incorporated into special videophones to permit remote diagnostic services, such as blood sugar level, blood pressure, and vital signs monitoring. Such units are capable of relaying both regular audio-video plus medical data over either standard (POTS) telephone or newer broadband lines.^[48]

A Tandberg T3 high-resolution telepresence room in use (2008)

Videotelephony has also been deployed in corporate teleconferencing, also available through the use of public access videoconferencing rooms. A higher level of videoconferencing that employs advanced telecommunication technologies and high-resolution displays is called telepresence.

Today the principles, if not the precise mechanisms, of a videophone are employed by many users worldwide in the form of webcam videocalls using personal computers, with inexpensive webcams, microphones, and free videocalling Web client programs. Thus an activity that was disappointing as a separate service has found a niche as a minor feature in software products intended for other purposes.

According to Juniper Research, smartphone videophone users will reach 29 million by 2015 globally.^[49]

A study conducted by Pew Research in 2010, revealed that 7% of Americans have made a mobile video call.^[50]

Government and law[edit]

In the United States, videoconferencing has allowed testimony to be used for an individual who is unable or prefers not to attend the physical legal settings or would be subjected to severe psychological stress in doing so, however, there is a controversy on the use of testimony by foreign or unavailable witnesses via video transmission, regarding the violation of the Confrontation Clause of the Sixth Amendment of the U.S. Constitution.^[51]

In a military investigation in North Carolina, Afghan witnesses have testified via videoconferencing.

In Hall County, Georgia, videoconferencing systems are used for initial court appearances. The systems link jails with court rooms, reducing the expenses and security risks of transporting prisoners to the courtroom.^[52]

The U.S. Social Security Administration (SSA), which oversees the world's largest administrative judicial system under its Office of Disability Adjudication and Review (ODAR),^[53]
